Mercedes-Benz R129 SL-Class 1990-2002

Model years 1990-1996 have 12 hydraulic cylinders in the top system.

Model years 1997-2002 have 11 hydraulic cylinders in the top system

(left tonneau cover lock cylinder omitted in model years 1997-2002).

Top Hydraulics does not service roll bar cylinders, which fail very rarely.

R129 Front Locking Cylinder Removal (PDF)
R129 Rear Locking Cylinder Removal (PDF)
R129 Tonneau Cover Lift Cylinder Removal (PDF)
R129 Tonneau Cover Lock Cylinder Removal (PDF)
R129 Bow Extension Cylinder Removal (PDF)
R129 Main Lift Cylinder Removal (PDF)
